UPS Eaton 5P1150iR 1150VA / 770W

Spesialis Elektronik – UPS Eaton 5P1150iR 1150VA / 770W

UPS Eaton Model 5P adalah UPS line-interactive fase tunggal, dengan rating daya 650-1550 VA. UPS ini tersedia dalam bentuk tower atau rak Opsi network card (Network-M2) akan menyediakan koneksi Gigabit Ethernet dan memastikan pemantauan UPS yang aman melalui antarmuka browser web HTTPS, protokol SNMP v1/v3, dan alarm email.

Teknologi utama:

baterai UPS Lithium-ion, manajemen baterai ABM, Gelombang sinus murni

Penggunaan:

Cocok untuk perusahaan pusat data berskala kecil dengan workstation, server, dan peralatan jaringan berteknologi tinggi. Perangkat ini juga cocok untuk Distribusi TI/komputasi tepi agar pengaturan di wilayah/cabang terpencil menjadi lebih cepat

Manageability

• The new graphical LCD display provides clear information on the UPS’s status and measurements on a single screen (in seven languages). Enhanced configuration capabilities are also available with easy-to-use navigation keys.
• The 5P can meter energy consumption providing kWh values through the LCD and Eaton’s power management software.
• Load segment control enables prioritised shutdowns of nonessential equipment during outages in order to maximise battery runtime for critical devices. Load segment control can also be used to remotely reboot locked-up network equipment or to manage scheduled shutdowns and sequential start-ups.
• The 5P offers Serial and USB connectivity, plus an extra slot for an optional communication card (including SNMP/ Web card or relay contact card). Eaton’s Intelligent Power® Software Suite compatible with all major OS including virtualisation software such as VMware and Hyper-V is included with each UPS.

Performance and efficiency

• Energy efficient UPS: With an optimised electrical design, the 5P provides up to 98% efficiency, reducing cooling and utility costs.
• Pure sinewave output: When operating in battery mode the 5P provides a high quality output signal for any sensitive equipment connected, such as active PFC (power factor corrected) servers.
• Adjustable tolerance and sensitivity: Users can maximise useful battery life by widening the input voltage window or adjustable input waveform sensitivity (via the LCD or software) to adapt the UPS to a specific environment (like Genset).

Availability and Flexibility

• The 5P is available in tower or Rack 1U format, providing unmatched energy density with up to 1.1kW in only 1U.
• Stronger, longer battery life: Eaton ABM® battery management technology uses an innovative three-stage charging technique that extends batteries by up to 50%.
• Batteries can be hot-swapped without ever having to shut down connected equipment. With an optional, hot-swap maintenance bypass module, you can even replace the entire UPS.

Technical Specifications UPS Eaton 5P1150iR 1150VA / 770W
